HW-UP(OP)300 Series (FDA Listed)
Tankless RO System
• HW-UP(OP)300 M :
Sediment Filter + Pre Carbon Filter + RO Membrane Filter + Post Carbon Filter + RO Pump
|
1. Features of HW-UP 300 Series
|
♦ Tankless Reverse Osmosis System
♦ Undersink type & Onsink type(Counter top)
♦ Use of RO 300 GPD Filter
* Average Flow Rate(GPD): 300 GPD
* Improving the TDS(Total Dissolved Solids) rejection(Rejection Rate: 97%)
* Meet all different water quality needs.
♦ With booster pump(Motor)
* Using the high quality booster pump that can provide 100-120psi water pressure to pass through the membrane even with areas under low water pressure.
♦ Basic permeate rate
* Inlet water oressure : 3kgf/cm²- Flow rate : 120LPH / Capacity of treated water : 300 GPD
♦ Specification
- Dimension : 325x180x430mm(WxDxH)
- Weight : 10.5kgs
|
2. Specification of parts
|
♦ RO 300GPD
* Operation pressure(psi): 65psi
* Average Flow Rate(GPD): 300 GPD
* Rejection Rate(%): 97%
* Recover Rate(%): 10%
♦ HIGH quality PUMP
- VOLTS : DC24V - INLET PRESSURE : 15~90psi - OPEN FLOW : 2.1LPM
- AMPS : 2.1A - WORKING PRESSURE : 82±8psi - SUCTION HEIGHT : 2M
- PRESSURE SETTING : BYPASS 125psi
|
| 1. Sediment Filter |
10 Low Pressure S/W |
| 2. Pre Carbon Filter |
11. Solenoid Valve |
| 3. Post Carbon Filter |
12. High Pressure S/W |
| 4. RO 300G Membrane Filter |
13. AC/DC Adapter |
| 5. M-Clip |
14. Cord Bushing |
| 6. M-M Clip |
15. Flow Restrictor |
| 7. Elbow 1/4" |
16. Check Elbow 1/8" |
| 8. Elbow Fitting 3/8" |
17. L-Fitting |
| NO |
Description |
| 1 |
Sediment Filter 11" |
| 2 |
Pre Carbon Filter 11" |
| 3 |
300GPD RO Membrane |
| 4 |
Post Carbon Filter 11" |
| 5 |
Pump |
| 6 |
Solenoid Valve |
| 7 |
Low Pressure Switch |
| 8 |
High Pressure Switch |
| 9 |
Check Valve |
| 10 |
Flow Restrictor |
| 11 |
Faucet |
| 12 |
Drain Connector |
| 13 |
Inlet Valve |
|
